VGA Board for LCD Display
Place of Origin: Shanghai, China
Model Number: ND-2660H
Send Inquiry
Product Details ofVGA Board for LCD Display
Hot Sale vga lcd controller board for lcd display for common size
Overview
Display Size | 7 inch |
Place of Origin | Shanghai, China |
Model Number | ND-2660H |
Brand Name | New display |
Type | AD board |
Supply Ability | 200000 Piece/Pieces per Month |
Packaging Details | original packing |
Port | Shanghai |
Specification
CPU | Mstar v59 HD Audio and video decoding chip |
Memory | SD/USB |
Decoding resolution | up to 1080p support |
Playback mode | supports full cycle , single cycle playback mode |
Video playback | Support extension :AVI , MP4, MPG, TS, VOB, MKV, MOV, RMVB, and other video , video encoding format :xvid , MPEG1, MPEG2, AVC, H.N, audio encoding format km:MP3, AAC2, WMA, COOK |
Video playback | Support mp3 |
Picture format | Support JPEG, BMP |
USB 2.2 interface | 1pc USB HOST |
Serial | 1pc |
IO control interface | 1pc |
LVDS output | 1pc , direct drive to 50/60hz LCD screen with maximum support for 1920x1080 |
Audio output | Amplifier output, direct drive 2*8Ω 5w speaker |
HDMI input | 1pc , stander hdmi interface |
RTC real time clock | support |
Timining switch machine | support |
Syeterm upgrade | support USB upgrade |
Power input | DC 12W |
Power | ≤5w, when the speaker /LCD /backlight inverter /USB device is not connected |
Operating temperature | 0℃~40℃ |
Operating humidity | 10℃~90 ℃ no condensation |
Drawings
Quality control:
Quality control involves testing of units and determining if they are within the specifications for the final product.
Quality testing involves each step of the manufacturing process. Employees often begin with the testing of raw materials, pull samples from along the manufacturing line and test the finished product.
We confirm 100% QC outgoing control before release shipment.
Packing and delivery:
● Payment terms: T/T
● Shipping: prompt delivery by UPS, EMS, DHL, TNT, and FedEx or by air
● Delivery lead-time: 7-10 days for goods in stock, 3-4 weeks for mass production goods
● Packing details: packed in anti-static bags with foam box to ensure safety in transportation
● Delivery details: 1 to 30 days, delivery fee is up to the weight or volume of the products
