Product Introduction

The touch is sensitive, the picture is vivid and has no afterimages. Anti-glare interference, itcan automatically adjust the brightness according to the environment. 2.0 Inch 240x320 TFT LCD with Touch Screen can work 7×24 hours uninterruptedly. And multi-period intelligent switch machine saves power, worry, and time. It has been applied in a wide range of industries including E-cigarettes, wearable devices, energy meter equipment, fiscal processors, portable devices, intelligent home solutions, medical facilities and industrial control.

Product Features

The 2.0 Inch 240x320 TFT LCD with Touch Screen's appearance is fashionable, and the surface adopts the aluminum molding process, which is round and beautiful. The all-steel body is matched with the IPS panel, all-metal design, high strength, high heat dissipation, and avoid magnetic interference in public places. With IPS panel, the picture can be displayed clearly at all viewing angles. Support multiple interfaces.

About us

DAS offers a wide product range of small to medium sizes TFT display modules in sizes ranging from 0.96” through 30”, no matter it is by engineering a custom display module, or by implementing a standard display from our wide selection of technologies, including being integrated with touch sensors and/or cover lenses. These TFT LCD modules are including options of TFT panel, TFT LCM with controller board, industry standard mono TFT LCM, TFT color display, IPS display and wide operating temperatures of -20°C to +70°C or -30°C to +80°C. The interface options are MCU / RGB / SPI / UART / 8080 / LVDS. We also offer customization of backlight or/and FPC. Our products have been applied in a wide range of industries including E-cigarettes, wearable devices, energy meter equipment, fiscal processors, portable devices, intelligent home solutions, medical facilities and industrial control.
With our automatic direct bonding process, we can also integrate these displays with customized capacitive touch panels and/or cover lens using lamination of OCA, SCA or OCR. We can also customize HDMI interface /serial interface adapter board.

Specification

Display Spec.	Size		2.0 inch
	Resolution		240(RGB)x320
	Display Type		Transmissive
	Color Depth		262K
	Dot Pitch(mm)		0.153(H)×0.153(V)
	Pixel Configuration		RGB Vertical Stripe
	Driver IC		ILI9341
	Viewing Direction		ALL
	Input Interface		MCU
Mechanical Characteristics	DIM.	LCM (W x H x D) (mm)	36.2. (W) x51.8(H) x 2.0( D)
	Active Area(mm)		30.6(W) x40.8(H)
	Backlight		White LED
	Weight (g)		TBD

Company advantages:

1. Product Knowledge

With a clear focus on and depth in current display technologies, out staff will suggest you our best solution.

2. Technical Support

Technical Interactions, Design proposal, Continuous improvement, hardware and software design support

3. Cost Effective Products

Offer one of the largest supplies of standard displays, state of the art ISO certified factories

4. Time to Market

3-5 days for counter drawing

2-3 weeks for LCD panel samples

5-7 weeks for various module samples

5-6weeks for LCD panel mass production

7-10 weeks for various modules mass production

5. Project Management

Focus on customer and market, effective communication, cross-functional team, preferential resource collocation

6. Complaint Management

Response by email or phone call in 24hours when having any inquiries

Prompt response RMA system

7. Value-add Services

In addition to modifying displays, we offer custom LCD/FPC/PCB, LED backlight and complete assembly productions.

Drawings

FAQ

Question1: Where to get the datasheet?
Please send mail to vivi.hou@das-tek.com ,we will reply you in 24hours.
Question2: How do you add the extra function ?
Carefully check with customer about request and get the 100% approval before work performed.
Question3: Payment terms of customized service and mass order?

30% deposit in advance,70% final payment before shipping.
Customized Service:
According to product requirement,50% T/T in advance, 50% after sample approval . we will provide 2~3pcs free sample.
