1.84 Inch 160x32 RGB Full Color OLED Display Module
1.84 inch 160X32 RGB full color OLED display module with high brightness and wide viewing angle
Product Introduction
Self-luminous pixels can be completely turned off without any light absorption. 1.84 Inch 160x32 RGB Full Color OLED Display Module provides accurate and stable color reproduction. With expandable and bendable performance, it can adapt to the requirements of different sizes and spaces. The color reproduction is accurate and stable. Multiple displays of a splicing module can display different screens separately.
Product Features
Ultra-high brightness, 1.84 Inch 160x32 RGB Full Color OLED Display Module is still clearly visible from a long distance under the sun's strong light. The color uniformity of the display screen is super high, and the screen picture is more delicate. It uses a variety of scanning technologies, and modular design requirements, higher reliability and stability. The circuit board adopts wave soldering process and has a green oil oxygen barrier to prevent moisture and oxidation of the circuit and increase the service life. It adopts a new type of surface mount package, the display is clearer and the color is more stable, it can realize single-point maintenance, and it is more efficient and energy-saving.
Overview
This is a full color OLED display module with 160(RGB)×32 dot matrix. The characteristics of this display module are high brightness, self-emission, high contrast ratio, slim/thin outline, wide viewing angle, wide temperature range, and low power consumption.
Features
● Display Color: Full Color
● Dot Matrix:160(RGB)×32
● Driver IC: SSD1352
● Interface:8-bit 8080
● Wide range of operating temperature: -40℃ to 70℃
Specification
NO. | ITEM | SPECIFICATION | UNIT |
1 | Dot Matrix | 160(W)(RGB)×32(H) | - |
2 | Dot Size | 0.066(W)×0.226H) | mm2 |
3 | Dot Pitch | 0.096(W)×0.246(H) | mm2 |
4 | Aperture Rate | 63 | % |
5 | Active Area | 46.05(W)×7.852 (H) | mm2 |
6 | Panel Size | 52.5(W)×16.0(H) ×1.2(T) | mm3 |
7 | Module Size | 52.5(W)×49.0(H) ×1.43(T) | mm3 |
8 | Diagonal A/A Size | 1.84 | inch |
9 | Module Weight | 2.21±10% | gram |
Service:
(1) Better manufacture ability
(2) Various payment term to choose:T/T,Western Union,L/C,Paypal
(3) High quality/Safe material/Competitive price
(4) Small order available
(5) Quickly response
Drawings
Packaging & Shipping
Packaging: 1. One piece in one carry bag
2. Suitable quantity to an export carton
3. No other packing accessories in regular
4. Customer required packing is available
Shipping: by air, sea, or express
Sample lead time: 5~7 days
Delivery time: about 25~30 days after order details and production confirmed.
